7

Powering Matrox MicroQuad

Removing/inserting adapter plug

Powering Matrox MicroQuad

1

Removing an adapter plug Inserting an adapter plug

Power

adapter

Adapter

plug

0

To A C

outlet

Matrox MicroQuad

Power supply

cable

Fasten the power

supply cable to Matrox

MicroQuad using the

locking connector.
