MATSONIC MS7102C - Appendix 1: Quick Jumper Setting Reference; JP1: Clear CMOS Memory Jumper

49
PANEL: Case Switches and Indicators
Use the Panel connector to implement the switches and indicators on the
system case.
Function Pins
Power Indicator 1+, 2+, 3
Sleep Switch 4, 5
Green Indicator 7+, 8+, 9
Keylock 10, 11
Reset Switch 12, 13
Speaker 15+, 16, 17, 18
Hard Disk Indicator 20+, 21
Power Switch 22+, 23
1
23
Speaker 15-16-17-18
Power LED 1-2-3
KeyLock 10,11
HDD LED 20-21
Reset SW 12-13
Sleep SW 4-5
Power SW 22-23
Green LED 7-8-9
PANEL
