Matsui 1410R - System Overview and Specifications; Technical Specifications; Connection Facilities

1
Technical specifications
CHASSIS CTN
Mains voltage : 220 - 240 V ± 10% AC; 50 Hz (±5%)
Power cons. at 220V~ : 35 W (stand-by 6W)
Aerial input impedance: 75Ohms - coax
Min. aerial input VHF : 30:V
Min. aerial input UHF : 40:V
Max. aerial input VHF/UHF : 180mV
Pull-in range colour sync. : ± 300 Hz
Pull-in range horizontal sync. : ± 600 Hz
Pull-in range vertical sync. : ± 5 Hz
Picture tube range : 14''
: Mono 4'' round full range 25W 1W.
TV Systems : PAL BG
: PAL I
: PAL BG / SECAM BGDK
: PAL BGI / SECAM BGLL'
Indications : On screen display (OSD) green and menu
: 1 LED (red in ON and blinking red in stand-by)
VCR programs : 0 to 79
Tuning and operating system : VST
UV1315AS / IEC (VST) : VHFa: 48 - 102 MHz
: VHFb: 138 - 224 MHz
: UHF: 470 - 861 MHz
U1343AS / IEC (VST) : UHF: 470 - 861 MHz
Local operating functions : Vol/Prog, +, -, contrast, colour and brightness.
2. Connection facilities
Euroconector:
1 - Audio
R (0V5 RMS ó 1K ). 17 - CVBS
2 - Audio
R (0V2 - 2V RMS ò 10K ). 18 - CVBS
3 - Audio
L ( 0V5 RMS ó 1K ). 19 - CVBS
( 1Vpp 75W ).
4 - Audio
20 - CVBS
( 1Vpp/75W ).
5 - Blue
21 -
Earthscreen.
6 - Audio
L (0V2 - 2V RMS ò 10K ).
7 - Blue (0V7pp/75W ).
8 - CVBS status 1
(0-2V int., 10-12V ext.).
9 - Green
10 - -
11 -
Green
(0V7
pp
/75W ).
12 - -
13 - Red
Head phone:
14 - -
15 - Red (0V7
pp
/75W ). 8 - 600
S
/60mW 3,5mm
ø
.
16 - RGB status (0-V4 int.) (1-3V ext. 75W ).
