26
3. Remove the top left screw cover.
4. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
5. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
2. Undo the screws. Then remove the hinge
bracket.
unscrew
• Do not lay the unit flat as this may
damage the coolant system.
• During door reversal, when
swapping the position of the
bottom hinge or adjusting the
levelling feet, tilt the unit. Do not
lay the unit flat.
