Matweld 03900A - 03940 A Clamp Assembly Parts; Clamp Assembly Component List

17
MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180
Matweld reserves the right to change parts, features, or specifications without notice.
9/99
03940A
CLAMP ASSEMBLY
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
PART
NO.
03955A
03917A
03918A
03949A
A2200
A2061
03948A
03920A
A2054
A2194
A1454
03922A
00806-01
03923A
03926A
A1481
00832
A1458
A1085
A1087
A3930A
DESCRIPTION
CLAMP BASE
BASE MOUNTING STUD
BASE ARM
SAW ARM RACE
¾” O WASHER
¾-16 NYLOCK NUT
BEARING
LINKING STUD
½-13 NYLOCK NUT
½” SAE WASHER
3/8-16 JAM NUT
MOUNTING ARM
3/16” KEY
DISCONNECT BOLT
CLAMP HANDLE
1” X 1” SHOULDER BOLT
CLAMP SCREW
½-13 JAM NUT
½-13 X 2” GR. 5 ZP
½-13 X 2-1/2” GR. 5 ZP
CRANK HANDLE KNOB
QTY.
1
1
1
6
5
4
6
1
1
1
1
1
1
1
1
1
1
2
1
1
1
REV.8/04
