15
3. NAME OF PARTS (See Fig.A)
Description of Functions of Key Components
1
Power switch
Turns on or off the power supply
2
Pressure-Reduction valve adjust-
ment handle (HIGH) (Orange cap)
Intended for exclusive use with the tool. It adjusts
the operating pressure of the tool.
3 Pressure-Reduction valve adjust-
ment handle (REGULAR) (Yellow
cap)
Adjusts the pressure supplied to the regular pressure
nailers and pneumatic tools (operating air pressure 8.3
bar (120psi) maximum).
4
Pressure gauge in the tank
Indicates pressure in the tank. The pressure increases
up to 34 bar (500psi).
5
Pressure gauge (HIGH)
It indicates the set pressure on the pressure-reduction
valves (HIGH).
(24.5 bar (335psi) maximum)
6
Pressure gauge (REGULAR)
It indicates the set pressure on the pressure-reduction
valves (REGULAR). (8.3 bar (120psi) maximum)
7
High pressure air chuck (for MAX
tools)
It connects the MAX air hose for the tools.
8
Regular pressure air chuck (for
regular pressure tools)
It connects the air hose for the regular pressure nailers.
9
Drain cock
It drains compressed air and water, Drain once when the
work is finished or more a day.
0
Power plug
It is usable with a triode ground outlet.
a
Power cord
b
Air tank
c
Rubber foot
d
Control panel
It allows switching the mode between Normal and Quiet.
(See Fig.B) For details of the LEDs and switches on the
Control panel, see "Control Panel" on page 16.
• Current consumption is reduced in the operation in
Quiet mode.
e
Grip for two-handed carry
f
Air chuck 44K
It connects the flexible pipe M-5 of lower three tanks.
g
Flexible pipe M-5
It connects the upper two tanks and the lower three tanks.
h
Stop plug
It seals the part to attach the air chuck 44K.
To Next Page
