maxam 10 series - ESC Advanced Settings and Reset; Resetting ESC to Defaults

3.9. Timing: There are many differences among structures and parameters of different brushless motors, so a fixed
timing ESC is difficult to compatible with all brushless motors. It is necessary to make the timing value
programmable. Please select the most suitable timing value according to the motor you are just using. Generally,
higher timing value brings out higher power output, but the whole
effi
ciency of the system will be slightly lower
down.
3.10. Over-Heat Protection: If the function is activated, the output power will be cut-off when the temperature of
the ESC is up to a factory preset threshold for more than 5 seconds. When the protection happens, the Green LED
will flash.
4. Reset All Items To Default Values
At any time when the throttle is located in neutral zone (except in the throttle calibration or parameters program
process), hold the “SET” key for over 3 seconds, the red LED and green LED will flash at the same time , which
means each programmable item has be reset to its default value.
USER MANUAL MAXAM XS 451
10
