maxem HOME Maxem 5 User Manual

28 29
EN
Index
What is Maxem? 29
Productspecications30
What do I need for the installation? 32
Installation steps
01 - Mounting of Maxem 34
02 - Connecting current transformers
Option2.1-Connecting current transformers on the grid connection 36
Option2.2-Connecting current transformers on the solar panels 36
03-ConnectingMIDkWh-meters     38
04 - Connecting charging station
Option4.1-ConnectingTesla Wall Connector 40
Option4.2-ConnectingKEBAcharging station 42
Option4.3-ConnectingICU charging station 44
05 - Commissioning by installer 45
EC Declaration of Conformity 70
What is Maxem?
From the meter cabinet, Maxem measures the energy use in the house and the energy
generation of solar panels. Based on this information, it manages the charging station,
batteryorheatpumpsmartly.Thus,ithelpstheusertomakeeasierandcheaperuseof
sustainableenergy.
Maxem intelligently manages the charging
speed based on home energy use and solar
production, preventing over current on the
grid connection.
Charging station
Today you can monitor the energy use of
your heat pump. In the near future Maxem
manages the power of your heat pump or
e-boiler in order to store solar energy in hot
water.
Heat pump or e-boiler
Maxem optimizes power consumption on
the main grid connection to prevent over
current. This makes it unnecessary to get an
expensive grid upgrade.
Grid
Maxem measures the energy production of
your solar panels. Soon available: let
Maxem manage your charger on the basis
of solar production. This way you use 100%
of your own solar energy.
Solar panels
Battery
Future vision: through intelligent
measuring and management Maxem
makes sure that all solar power is stored in
the home battery. This way you use all your
solar energy locally.
