maxem HOME Maxem 5 User Manual

30 31
EN
01 - Voorbereidingen vooraf
Content of the box
MIDkWh-meterextension
Maxem including mounting plate
6x split core
current transformer
RS485 cable
Networkcable
Power cable
4x Screws 3x20
1x Phoenix connector
Productspecications
2x Tie-wrap
SET
OK
1 2 3
MIDkWh-meter
DenitionsLEDindicators
On/o
Internet
Data
connection
Current
measurement
Charging station
1x Phoenix connector
P1
port
Ethernet port
to charging station
Ethernet port to Internet
Router
230V power
supply
Current transformers
solar panels
Multi functional
USB port
Current transformers
grid connection
RS485
port 1
RS485
port 2
Denitionsinput/outputports
Specications
Dimensions 184 mm (L) x 167 mm (W) x 55 mm (H)
Weight 700g
Workingtemperature 10°C to 35°C
Storage temperature 0°C to 60°C
Maximal humidity 80%
Protection class II (double insulated)
Seal IP20
Workingheight 0to2,000m
EMC EN61326-1(2013),EN61000-3-2,61000-3-3
Safety EN61010-1(2010),EN61010-2-30(2010)
Immunity EN 61326-1 (2013)
Overvoltage category 300V/CAT III
Input power 110-240V.50/60Hz.Maximum2,75W
Power coils Up to 50A
REVISION
TITLE:
A4
DWG NO.
SCALE:1:2 SHEET 1 OF 2
WEIGHT:
A A
B B
C C
D D
E E
F F
4
4
3
3
2
2
1
DATESIGNATURE
DO NOT SCALE DRAWING
MATERIAL:
NAME
1
DRAWN
LINEAR:
CHK'D
APPV'D
MFG
Q.A
ANGULAR:
FINISH:
TOLERANCES:
EDGES
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
DEBURR AND
BREAK SHARP
Maxem5-R4
