Connection & Setting
7("$BCMF
64#$BCMF
For the safety of you and the machine, please do not connect any
power plug before connection.
1.External Computer and Touch Connection
NoteὉ
External computer input, equipment's best resolution is 1920*1080.
External computer can also connect to the equipment through the HDMI cable.
Recommended computer configurationὉ
2.0GHz above Processor, 2GB above Memory
More than 256 color display card
VGA-OUT/HDMI-OUT, Audio-OUT, USB Interface
Support Resolution 800*600, 1024*768, 1920*1080
$PNQVUFS
"VEJP$BCMF
(1) Use VGA cable to connect to VGA output port of external computer, and meanwhile use
headphone audio cable to connect to external computer audio output interface
(2) Use USB cable to connect to external computer USB port
(3) After cable connection, plug in power cord,and switch power on
(4) Start external computer
(5) Press to turn equipment on
(6) Press INPUT key to switch to VGA channel
