13
2) HDMI OUT Connection
1> Use HDMI cable to c onnect display device with HDMI IN
2> Plug in the power cord and switch the AC switch to "I"
3> Press
to turn equipment on
4> HDMI signal output to display device
3) USB Connection
4) AUX OUT Connection
HDMI Cable
HDMI OUT
Display
USB Cable
USB Device
USB
Audio Cable
AUX OUT2
CANNON
AUX OUT1
Power amplifier/stereo equipment
