4a4
3
Assembly
3
5
3 Install Rear Wheels
Insert rear wheel axle into the frame
until you hear a “click” (Figure 3).
Repeat for other rear wheel. Pull to
confirm wheels are assembled securely.
NOTE: To remove rear wheel press
release button (Figure 3).
4 Install Front Wheels
Insert front wheels until you hear a “click”
(Figure 4).
NOTE: To remove front wheel, rotate
wheels to side (as shown). Insert long
thin screwdriver into hole on hub to
depress pin, then pull wheel out
(Figure 4a).
Release
Button
5 Install Seat
Lower seat onto towers
until you hear
each side “click” (Figure 5). Pull up to
confirm seat is assembled securely.
NOTE: Seat may face forward or
handlebar (Figure 5a).
To remove seat,
press both
release buttons
while lifting
seat up.
5a
Towers
To Next Page
