System testing before actual use
(Do not do any testing using a vehicle)
Familiarize yourself with the electronic controls and warning lights by reviewing
the functions of each item listed below.
The Electronics:
The electronic control system of ML-4030BC and ML-4034BC includes one master and three
slave control panels. The electronic control system of the ML-6045BC and ML6051BC includes
one master and five slave control panels. Each column has one displacement sensor, one
electric hydraulic pump, one micro-switch, and one electromagnet.
The photos below illustrate the Master and Slave control panels
Master Control Panel
