INSTALLATION OF THE DEVICE
The following has to be accomplished by the user:
Power supply connection of the machine should be
checked by an eligible electrician, and it should be
connected to a socket/outlet which is no higher than
170cm.
The screw for grounding when
To ground the device, the grounding cable should be
attached to the correct spot in the plug.
At about 25-50cm high in the wall there should be
1/2" water supply pipe for the machine with 3/4" tap
connection to supply the machine with water.
The power supply connection should be made using
a 30 mA current leakage fuse as a protection against
current leakage danger.
The drain should be attached to a 40-50mm wide
drain pipe which is at a maximum of 2cm above the
ground when using the normal VNG350. When you
are using the VNG350 Ultra you can place it at a
maximum of 60cm above the ground. This should be
behind the machine.
Do not forget to place the detergent and rinse hoses
in the corresponding cans and place the weights and
the end of the hoses, so they stay inside the can. The
normal VNG350 only has a rinse hose.
The feet of the machine are adjustable and should
be adjusted in such a position that the machine can
operate in a leveled position.
The working environment of the machine should be
free of steam and moisture. So be sure there is
enough ventilation or a ventilation hood for the
machine.
