KEY PARTS DIAGRAM
No. Description
1 Motor
2 Air filter cap
3 Tank pressure gauge
4 Pressure relief valve
5 Pressure switch
6 Power cord
7 Air tank
No. Description
8 Wheel
9 Check valve
10 AUTO/OFF switch
11 Pressure regulator knob
12 Air line outlet
13 Regulated pressure gauge
14 Handle
9
11
12
3
4
5
6
7
13
2
1
14
10
8
WARNING!
Remove the compressor and any accessories from the
package. Make sure that all items listed in the packing list
are included.
Inspect the compressor carefully to make sure no
breakage or damage occurred during shipping.
Do not discard the carton or any packaging material until
all parts have been examined.
