Maximum 058-9317-8 - Set Regulator and Power On; Adjust Hose Pressure

5
TM
QUICK START GUIDE
Adjust the hose pressure
gradually with respect to the
operating pressure of the air
tool by turning the pressure
regulator knob (1) clockwise.
See page 17, step 6.
5
Turn the pressure regulator knob (1)
counter-clockwise completely. Plug
in the power cord (2) into electrical
outlet. Turn the AUTO/ OFF switch
(3) to the AUTO position.
See pages 16-17, steps 3-5.
