22
CAUTION
!
NOTE: Some Liftgates are equipped with single or dual cart stops.
Cart stops prevent loaded carts from rolling off outboard end
of platform. Single cart stops are 1 section, about the same
as overall width of platform, and operate with one set of
controls. Dual cart stops are 2 identical sections, with a com-
bined width about the same as overall width of platform, and
each is independently operated with separate controls (1 set
of controls per cart stop). The following procedure shows dual
cart stops. A single cart stop operates the same way.
1. At ground level, move load
on platform with cart stops as
shown in FIG. 22-1.
To prevent injuries caused by tripping and falling, make sure
cart stops are closed before walking on and off outboard end of
platform.
LOADING PLATFORM AT GROUND LEVEL
(CART STOPS CLOSED)
FIG. 22-1
NOTE: Cart stops are usually closed when not in use. If you fi nd the
carts stops are already open when rolling a load from the
ground to the platform, you may roll the load over the cart
stop. The cart stop will close temporarily as the load crosses
and reopen when the load is off the cart stop.
CART STOPS
USING CART STOPS (IF EQUIPPED)
To Next Page
