clockwise.
⑤WIDTH (width control knob)
Controls modulation depth. Turn this
knob clockwise for deeper
modulation.
⑥RATE (rate indicator)
Indicates phase shift speed rate.
LED brightness synchronizes with
phase shift speed set by speed
control knob.
⑦FOOTSWITCH
Switch for effect on/off. Stepping on
this switch alternately turns effect on
and off.
* Effect turns on when you depress
the switch and effect turns off when
you depress and release the switch.
⑧INDICATOR
This indicates the effect/bypass
status and battery condition. It
lights when plug is inserted into
input jack and effect is on with
footswitch. No LED light indicates
the battery is low or not installed.
In this case replace the battery.
⑨DC IN (power input jack)
Jack for connection of external
power supply to effect. Be sure to
use the correct Maxon AC
adaptor.
Turn down amplifier’s
volume to the minimum
before connecting AC adaptor to
the product in order not to damage
other connected equipment.
21
ENGLISH
PT9Pro+
●RATE LED brightness synchronizes with phase shift speed. It makes it easy
to see the rate.
●True Bypass Switching using 4PDT switch lets your instrument’s signal pass
through a non-electronic bypass line when the effect is disengaged, feeding
your amp with direct, unaltered signal from your instrument.
●Easy-access, no tools battery compartment.
