Input Impedance
Output Impedance
Maximum Gain
Equivalent Input Noise
Control
Switch
Indicator
Internal Circuit Voltage
Power Consumption
Dimensions
Weight
Power Supply
Battery Life
Option
* 0dB = 0.775Vrms
* All specifications are subject to change for improvement without notice or obligation.
: 500k ohms
: 10k ohms or less
: 51dB (2.2kHz)
: -115dB or less (IHF-A)
: MID ENHANCE, DRIVE, TONE, LEVEL
: Bypass/Effect, Voltage Switch (9V/18V)
MODE Switch (CLASSIC/LOW BOOST)
: Bypass/Effect LED, 9V LED, 18V LED
: 9VDC / 18VDC (DC to DC Converter)
: 12mA/9VDC, 36mA/18VDC
: 74 (W) ×124 (D) × 54 (H) mm
: 610g (including battery)
: 6F22 / 6LR6 9V battery × 1 or Maxon AC adaptor
: 9VDC manganese battery 26 hours 25℃(Panasonic 6F22NB)
: 9VDC alkaline battery 48 hours 25℃(Panasonic 6LR61G)
: 18VDC manganese battery 2 hours 25℃(Panasonic 6F22NB)
: 18VDC alkaline battery 8 hours 25℃(Panasonic 6LR61G)
: AC adaptor (Refer to page 29.)
23
CONNECTION DIAGRAM
SPECIFICATIONS
ENGLISH
ST9Pro+
