25
●SM9Pro+ has increased dynamic headroom with internal operating voltage set at 18V.
Stable high-quality sound is available as unintentionally-generated distortion is significantly re-
duced.
●TBS (True Bypass Switching) using 4PDT mechanical switch lets your instrument's signal
pass through a non-electronic bypass line when the effect is disengaged, feeding your amplifi-
er with direct, unaltered signal from your instrument. No tone changes when the effect is en-
gaged as signal does not pass through electronic switching circuitry. This TBS gains enor-
mous popularity among artists.
●Easy-access, tool-free battery compartment.
⑦FOOTSWITCH
Switch for effect/bypass. Stepping on this switch
alternately turns effects on and off.
* Effect turns on when you depress the switch and
effect turns off when you depress and release the
switch.
⑧BYPASS/EFFECT INDICATOR
This indicates the effect/bypass status and battery
condition. At battery operation, it lights when plug
is inserted into input jack and effect is on. At the
external power supply (AC adaptor) operation, it
lights when effect is on. No LED light indicates the
battery is low or not installed. In this case replace
the battery.
⑨9V INDICATOR
This indicates the operating voltage status. It lights
when 9V is selected.
⑩18V INDICATOR
This indicates the operating voltage status. It lights
when 18V is selected.
⑪DC INPUT (power input jack)
Jack for connection of external power supply to ef-
fect. Be sure to use the correct Maxon AC adap-
tor.
* Turn down amplifier's volume to the min-
imum before connecting AC adaptor to the
product in order not to damage other connected
equipment.
⑫OPERATING VOLTAGE SWITCH
Slide it to right side for 9V and left side for 18V.
* Turn down amplifier's volume to the mini-
mum before switching.
ENGLISH
SM9Pro+
