SPECIFICATIONS
MODEL
SUNBRIDGE PV6000
RATED OUPUT POWER
5000W
PV INPUT (DC)
Max. PV Power
6000W
Max. PV Array Open Circuit Voltage
450 VDC
MPPT Range @ Operating Voltage
120 VDC~430 VDC
Max. PV Array Short Circuit Current
27A
Number of MPP Tracker
1
GRID-TIE OPERATION
GRID OUTPUT (AC)
Nominal Output Voltage
220/230/240 VAC
Feed-in Grid Voltage Range
195.5~253 VAC @India regulation
184 ~ 264.5 VAC @Germany regulation
184 ~ 264.5 VAC @South America regulation
Feed-in Grid Frequency Range
49~51Hz @India regulation
47.5~51.5Hz @Germany regulation
57~62Hz @South America
Nominal Output Current
21.7A
Power Factor Range
>0.99
Maximum Conversion Efficiency (DC/AC)
95%
OFF-GRID, HYBRID OPERATION
GRID INPUT
Acceptable Input Voltage Range
90 - 280 VAC or 170 - 280 VAC
Frequency Range
50 Hz/60 Hz (Auto sensing)
Transfer Time
< 10ms (For UPS)
< 20ms (For Home Appliances)
< 50ms (For parallel operation)
Rating of AC Transfer Relay
40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
220/230/240 VAC
Output Waveform
Pure Sine Wave
Efficiency (DC to AC)
93%
BATTERY & CHARGER
Nominal DC Voltage
48 VDC
Maximum Charging Current (from Grid)
80A
Maximum Charging Current (from PV)
80A
Maximum Charging Current
80A
GENERAL
Dimension, D X W X H (mm)
140 x 295 x 468
Net Weight (kgs)
12
INTERFACE
Parallel-able
Yes
External Safety Box (Optional)
Yes
Communication
RS232/Dry-Contact/WiFi
ENVIRONMENT
Humidity
0 ~ 90% RH (No condensing)
Operating Temperature
-10°C to 50°C
