Maxton UC1A - EXTERIOR DIMENSIONS UC1 A

1728 Orbit Way - Minden, Nevada 89423 P: 775-782-1700 F: 775-782-1701 info@maxtonvalve.com www.maxtonvalve.com

15
\\SERVER\CATALOG2019\2019CatalogRev2

TANK
JACK
3 1/8"
(79mm)
4 3/4"
(121mm)
8"
(203mm)
11 1/4"
(286mm)
3 1/2"
(89mm)
4 1/2"
(114mm)
Top View
JACK
TANK
12 3/8"
(314mm)
5 3/8"
(137mm)
PUMP
1 29/32"
(48mm)
4 3/4"
(121mm)
7 7/8"
(200mm)
13"
(330mm)
Front View
+
EXTERIOR DIMENSIONS UC1A
PUMP
(BELOW)
