Maxton UC1A - SHUT OFF BALL VALVE; SPECIFICATIONS; VALVE MODEL WEIGHT

1728 Orbit Way - Minden, Nevada 89423 P: 775-782-1700 F: 775-782-1701 info@maxtonvalve.com www.maxtonvalve.com

89
\\SERVER\CATALOG2019\2019CatalogRev2

Maxton Elevator Shut Off Valves are specifically built for hydraulic elevators and are
labeled and tested to comply with ASME A17.1 / CSA B44 at a 5:1 Safety factor.
 Hard chrome plated carbon steel ball
 Blow out proof stem used across the line
 Unique locking handle design preventing
accidental fluid loss
 2 year Maxton valve warranty
 Interchangeable flange sizing of 2” & 2.5”
grooved or threaded connections (contact
Maxton for combinations not listed below)
SHUT OFF BALL VALVE
TOPVIEW
FRONTVIEW
Handleis
rotated90°
Todisplay
closedposion
SPECIFICATIONS
Oil Type Hydraulic Fluid
Max. Operating Temperature  150° F (65° C)
Max. Operating Pressure 1000 psi (69 bar)
Line Connections 2”, 2.5”, Grooved or NPT
Valve Type 1/4 Turn, Ball

3” Grooved
BV2G2G
SHOWN
11-13/16
(300mm)
6-1/4
(159mm)
3-1/8
(79mm)
6-11/16
(170mm)
8-11/16
(221mm)
10-15/16
(278mm)
2-1/4
(57mm)
4-1/2
(114mm)
2-1/4
(57mm)
BV2G2G
2" Full Port Grooved
11.30lbs. (5.13 kg)
BV2T2T
2" Full Port NPT
13.05 lbs. (5.92 kg)
BV25G25G
2.5" Grooved
11.65 lbs. (5.28 kg)
BV25T25T
2.5" NPT
11.65 lbs. (5.28 kg)
BV3G3G
3" Grooved
13.30 lbs. (6.03 kg)
VALVE MODEL WEIGHT
