Description of the winch
MAXWALD skidding winch
Drive: via prop shaft / duplex roller chain
Clutch: dry single-disc clutch
Brake: automatic disc brake
(dead-man system, patented by MAXWALD)
Operation / control: a) with rope control
b) with rope control and hydraulic clutch cylinder / alternative 0
c) with remote cable control / (electro-hydraulic) control panel /
alternative IV
d) with radio control ("intermittent brake")
Cable spooling device: for A 516 S and M2000-Premium
Cable entry brake/cable discharge:
OPTION, for winches with alt. IV,
M2000 Premium series
Equipment: OPTION - lower cable entry roller
- lateral hoop guards
- tool box
etc.
Type
A501(U), A501S(U),
A5000(U), A516S(U),
M2000 Premium
A611S, A6000
Permissible load at bottom
layer:
6.5 t
7.0 t
Permissible load at top
layer:
4.5 t
5.0 t
Max. cable capacity:
100 m/10 mm or 80 m/11
mm
160 m/10 mm or 130 m/11
mm
90 m/11 mm
Required cable breaking
strength:
130 kN
140 kN
Rated strength:
1960 N/mm²
1960 N/mm²
Max. drive speed:
540 rpm
540 rpm
Recommended tractor
power:
50 PS
60 PS
For alternative IV / radio
control:
Control pressure:
140 bar
140 bar
Voltage:
12 volt
12 volt
Ideal cable length = max. cable capacity – 15 %
