Maxwell Digital Multimeters 25 222 - Page 5

dC voltaGe
Measuring range Resolution Accuracy
400 mV 0,1 mV
± (0.5% + 3)
4 V 1 mV
40 V 10 mV
± (0.8% + 3)
400 V 100 mV
600 V 1 V ± (0.8% + 5)
• Input resistance: 10 MΩ
• Overvoltage protection: 250 V DC or 250 V AC
RMS value in 200 mV measurement range
• In further measurement limits: 600 V DC or
600 V AC RMS value
aC voltaGe
Measuring range Resolution Accuracy
400 mV 0,1 mV
± (1.0% + 10)
4 V 1 mV
40 V 10 mV
400 V 100 mV
600 V 1 V
• Input resistance: 10 MΩ
• Overvoltage protection: 250 V DC or 250 V AC
RMS value in 200 mV measurement range
• In further measurement limits: 600 V DC or
600 V AC RMS value
• Frequency measurement: 40 Hz – 1000 Hz,
True RMS display
dC CUrrent
Measuring range Resolution Accuracy
400 µA 0,1 µA
± (1,8% + 5)4000 µA 1 µA
40 mA 0,01 mA
400 mA 0,1 mA ± (2,5% + 5)
4 A 0,001 A ± (3% + 5)
10A 0,01 A ± (3% + 5)
• Overvoltage protection fuse:
F200 mA / 250 V (6,35 mm x 32 mm)
F10 A / 250 V (6,35 mm x 32 mm)
aC CUrrent
Measuring range Resolution Accuracy
400 µA 0,1 µA
± (1% + 5)4000 µA 1 µA
40 mA 0,01 mA
400 mA 0,1 mA ± (2% + 5)
4 A 0,001 A ± (3% + 5)
10A 0,01 A ± (3% + 5)
• Overvoltage protection fuse:
F200 mA / 250 V (6,35 mm x 32 mm)
F10 A / 250 V (6,35 mm x 32 mm)
• Frequency range: 40 Hz – 1000 Hz, True RMS
display
resistanCe
Measuring range Resolution Accuracy
400 Ω 0.1 Ω
±(1.0% + 5)
4 kΩ 0,001 kΩ
40 kΩ 0,01 kΩ
400 kΩ 0,1 kΩ
4 MΩ 0,001 MΩ
40 MΩ 0,01 MΩ ±(1.2% + 8)
• Overvoltage protection: 250 V DC / AC RMS
diode and ContinUity test
Mode
Diode test
• The display shows the opening voltage
of the diode
Continuity test
• A beeping sound indicates when the
resistance is less than 70 Ω
• Overvoltage protection: 250 V DC / AC RMS
battery testinG
Measurement limit Kijelző érték Accuracy
1,5 V 1,5 V 0,01 V
3 V 3 V 0,01 V
9 V 9 V 0,01 V
• Overvoltage protection: 36 V DC vagy 36 V AC RMS
EN
User Manual
