Overload
protection
0,5 A / 250 V „F” mark fuse, 10 A
/ 250 V fuse
AC current
Range Accuracy Resolution
400 μA
+/- (1,5%
+ 5)
0,1 μA
4 mA 1 μA
40 mA 10 μA
400 mA 100 μA
10 A
+/- (2,0% +
15)
10 mA
Overload
protection
0,5 A / 250 V „F” mark fuse, 10 A
/ 250 V fuse
Frequency
range
400mA: 40-400Hz • 10A: 40-
100Hz
Kapacitás
Range Accuracy Resolution
4 nF
+/- (2,5%
+ 6)
1 pF
40 nF 10 pF
400 nF
+/- (3,5%
+ 8)
100 pF
4 μF 1 nF
40 μF 10 nF
200 μF +/- (5,0% +
8d)
100 nF
Overload
protection
250V AC/DC RMS
Diode test
Function Description Test state
Measures
the opening
voltage of the
diode
Opening DC
current appr. 0,5
mA
Closing DC
voltage appr.
1,5 V
If the resistance
between the V/
Ohm and the
COM is lower
than 50 Ω the
device beeps
Opening
voltage appr.
0,5 V
Overload protection
250 V DC / AC
RMS
Warning: Do not connect an outside power source to the
wires!
Frequency
Range Accuracy Resolution
100 Hz
+/- (0,5%
+ 4)
0,01 Hz
1000 Hz 0,1 Hz
10 kHz 1 Hz
100 kHz 10 Hz
1 MHz 100 Hz
30 MHz 1 kHz
Inward sensitivity 0,7 V
Overload protection
250 V DC / AC
RMS
Temperature
Range Accuracy Test state
(-40–
1000)°C
<400°C ±
(0.8%+4)
>400°C ±
(1.5%+15)
1°C
With a K type temperature measurement
sensor
Temperature measurement
• Set the function switch to the „C” position.
• Connect the probe's connector to the „K
TEMP” connector (note the polarity) and the
other end onto the measured surface. The
temperature is displayed on the screen in °C
