Model 70275 Page 7
Parts List
Assembly Drawing
1 Carrier Basket 1
2 Hitch Bar Assembly 1
3 Ramp I 1
4 Ramp II 1
2niP-R5
2niP-U6
7 Ring 4
8 Chain 2
20 Lock Nut 4
21 Bolt 2
22 Rubber Foot 2
23 End Cap 2
24
2
25 Spring Washer 4
26 Nut 4
27 Big Washer 6
28
Bolt 2
29 Nut 2
30 Washer
Anti-Tilt Bracket
2
113
32 U-Pin Bracket 2
33 End Cap 2
34 End Cap 2
Part # Description QtyPart # Description Qty
TRAFFIC SIDE
CURB SIDE
When assembling this Carrier
make sure the Carrier Basket
and Ramps are oriented as
shown in the Assembly Draw-
rearward); for safety, Ramp
must open towards “curb side”
of vehicle. It can be hazardous
to open the Ramp towards the
WARNING
Note: The Parts List and Assembly Diagram is provided as
a reference tool only. Some parts are listed and shown for
illustration purposes only, and are not available as replace-
ment parts. All repairs to this tool (including replacing
-
cian.
Manufactured and Distributed by:
PGS LLC, 1270 Avenida Acaso STE E, Camarillo, CA 93012
Tel: 805-987-1333 Fax: 805-603-1355
PGS LLC ensures complete satisfaction with this product. In the event of miss-
ing or damaged parts please call toll free, Customer service hours 9:00-5:00, Monday-Friday, PST.,
1-805-987-1333
Hitch Bar Assembly (2) is assembled
underneath Carrier Basket (1).
9 Hitch Pin 1
10 Safety Pin 1
11 Bolt 14
12 Nut 14
13 End Cap 1
14 Tie Down Hook 4
15 Washer 26
16 Nut 4
17 Screw 38
18 Nut
38
19 Bolt
2
