Maytag MGDE500WJ1 - Page 2

TOP AND CONSOLE PARTS
2
(Magna Red) (Oxide)
For Models:MGDE500WR1, MGDE500WJ1
W10303330
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10239302 Use & Care Guide
W10255469 Installation
Instructions
W10258377 Tech Sheet
2 Top
W10164743 Oxide
W10249738 Red
3
W10111069 Harness, Main
4 Console Assembly
W10269246 Oxide
W10269245 Red
5 3394427 Clip, Harness
6
W10215656 Bracket, Console
(Includes No. 16)
7 353424 Connector, Sensor
8 94614 Terminal
9 3936144 Plug, Terminal
10 94613 Terminal
11 3390647 Screw, 8−18 x 1/2
12 8572039 Seal,
User Interface
13
W10177245 Medallion
14 3936150 Connector,
7−Circuit
15 3395683 Connector,
(Motor)
16
W10112267 Foam, Seal
Control Bracket
17 2203186 Connector,
5−Circuit
18 3403498 Connector,
3−Position
(Gas Valve)
19 3403499 Connector,
2−Position
(Gas Valve)
20
W10164576 Knob
21
W10269025 Techbox Assembly
22
W10171504 Foil−Display
23
W10214555 Plug−Connector
Frame
24 8540282 Screw
25 8540513 Screw
26
W10170295 Frame−Light Guide
27
W10170293 Guide, Light
Cylcle Internal
28
W10164567 Cycle, Light Guide
29
W10172298 Bushing, Knob
30
W10242907 Power Cable
User Interface
31
W10164578 Guide, Light
(3−Way Digital)
32
W10171502 Frame−Light
(Guide Display)
33
W10215674 Shield,
Console Bracket
34
W10216201 Plug−Hole 1/4"(2)
35
W10216202 Plug−Hole 5/16"(1)
