TOP AND CONSOLE PARTS
2
For Model: MGDZ600TW2, MGDZ600TB2, MGDZ600TK2, MGDZ600TE2
(White) (Black) (Pacific Blue)(Ocean Sapphire)
W10180622
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10260034 Use & Care Guide
W10261613 Installation,
Instruction
W10133923 Tech Sheet
2 Top
8563730 White
W10129703 Black
W10140767 Pacific Blue
W10174561 Ocean Sapphire
3
W10251443 Harness, Main
4 Panel, Console
(Includes Illus.
12.)
W10117389 White
W10117393 Black
W10119034 Pacific Blue
W10174674 Ocean Sapphire
5
W10119050 Knob, Assembly
6 8565237 Bracket, Console
7
W10117387 Lens, Display
8 3400238 Screw, 2−28 x 1/2
9
W10117417 Assembly,
User Interface
10
W10266747 Channel, Water
11 3390647 Screw, 8−18 x 1/2
12
W10203949 Badge Assembly
