CABINET PARTS
4
For Model: MGDZ600TW2, MGDZ600TB2, MGDZ600TK2, MGDZ600TE2
(White) (Black) (Pacific Blue)(Ocean Sapphire)
W10180622
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8317340 Cover,
Terminal Block
2 3390814 Screw, 8−18 x 3/8
3 8533974 Screw Ground
4 Panel, Side (R.H.)
8565048 White
W10112963 Black
W10119027 Pacific Blue
W10174558 Ocean Sapphire
5 3394881 Switch, Broken
Belt
7 Panel, Side (L.H.)
8565054 White
W10112962 Black
W10119026 Pacific Blue
W10174559 Ocean Sapphire
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 Plug, Multivent
49252 White
3388309 Black
8561800 Pacific Blue
W10151499 Midnight Grey
13 3388672 Pulley Assembly
14 3978776 Bracket,
Gas Pipe
15 8066120 Lever, Snap
Switch
16
W10167612 Wire, Belt Switch
17 343641 Screw, 8−18 x 1/2
18
W10121334 Washer, Thrust
19
W10128087 Assembly,
Door Switch
20 690997 Tri Ring
21 8066115 Cover−Plate
22 8565083 Ramp, Door
23 8565122 Strike, Door (1)
24 8572546 Kit,
Stack Assembly
25 8519459 Clip, Toe Panel
26 8565059 Panel, Rear
27 8538263 Motor Assembly
60 HZ.
28 3398948 Wire, Jumper
(Broken Belt
Switch)
29 8578220 Pulley 60 HZ.
30
W10112954 Belt, Drive
31 8529757 Bracket, Burner
32 3387118 Bracket, Motor
33 3401401 Cord, Power
34 49026 4" − 90
Elbow
35 693995 Screw, 8−18 x 3/8
36 8563747 Exhaust Pipe
& Bracket
37 8563750 Exhaust Pipe
(Short)
38 8563749 Exhaust Pipe
(Long)
39 3388674 Idler Bracket
40 Toe Panel
8540621 White
W10112964 Black
W10119028 Pacific Blue
W10174590 Ocean Sapphire
41 8533971 Screw, 8−18 x 5/16
42 98129 Screw,
6−20 x 1 1/16
43 3390647 Screw, 8−18 x 1/2
44 3387242 Seal, Front Panel
45 8565046 Base, Cabinet
46
W10111606 Control Board
47 8563727 Control Bracket
48
W10085210 Label−Hinge Hole
Cover
49 3357011 Screw, 8−18 x 1/2
50 Front Panel
(Includes
Illus. 44)
W10117421 White
W10117396 Black
W10119029 Pacific Blue
W10174660 Ocean Sapphire
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
51 279818 White
279820 Black
280102 Pacific Blue
W10186596 Midnight Grey
