BULKHEAD PARTS
6
For Model: MGDZ600TW2, MGDZ600TB2, MGDZ600TK2, MGDZ600TE2
(White) (Black) (Pacific Blue)(Ocean Sapphire)
W10180622
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3
W10153413
Door, Lint
Screen
4 3392519 Thermal Fuse
(91
C)
5 3394346 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
9
W10153409
Baffle, Drum
10 3402841 Lens,
Drum Light
11 359625 Screw, 8−18 x 1/2
12 8572105 Clip, Exhaust
Pipe
13 8533971 Screw, 8−18 x 5/16
14 8565061 Bulkhead, Front
15 693995 Screw, 8−18 x 3/8
16
W10001120
Nut, 3/8−16 (L.H.)
17
W10080170
Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8563728 Exhaust Pipe
23
W10153423
Housing, Outlet
Assembly
24 489463 Screw, 8−18 x 5/8
25
W10153420
Complete Drum
Assembly
26
W10219342
Screw, 8−16 x 1/2
27
W10166807
Seal, Drum
28 8066208 Clip−Spring
29 90767 Screw, 8−18 x 3/8
30
W10153412
Grille, Outlet
31
W10049370
Lint Screen
32 3401707 Wire Jumper
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 8578825 Bracket,
Drum Light
36
W10214261
Socket Assembly
37 697772 Wheel, Blower
38 8573713 Thermal Cut−Off
39 3394986 Spring, Lint
Screen Door
40 697770 Seal,
Cover Plate
41 695240 Screw, 8−18 x 1/2
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 8573824 Funnel, Burner
47 3391912 Thermostat,
High−Limit 205
F
(96
C)
48 338906 Sensor, Radiant
49 3387230 Screw, 10−16 x 1
50
W10110975
Harness,
Moisture Sensor
51 3406653 Harness, Sensor
52 3401850 Harness, Gas
To Next Page
