6
Custom undercounter installation - Dryer only
*Required spacing
Closet installation - Dryer only
*Required spacing
**For side or bottom venting, 0" (0 cm) spacing is allowed.
Recessed or closet installation - Dryer on pedestal
*Required spacing
**For side or bottom venting, 0" (0 cm) spacing is allowed.
Recommended installation spacing for cabinet installation
 For cabinet installation, with a door, minimum ventilation openings in the top of the
cabinet are required.
*Required spacing
**For side or bottom venting, 0" (0 cm) spacing is allowed.
A. Side view - closet or confined area
B. Closet door with vents
0"
(0 cm)
1"*
(2.5 cm)
1"*
(2.5 cm)
38" min.
(96.52 cm)
27"
(68.6 cm)
A
B
14" max.*
(35.6 cm)
18" min.*
(45.72 cm)
1"*
5"**
(12.7 cm)
31½"
(80 cm)
48 in.
2*
(310 cm
2
)
24 in.
2*
(155 cm
2
)
3"*
(7.6 cm)
3"*
(7.6 cm)
(2.5 cm)
A. Recessed area
B. Side view - closet or confined area
AB
1"
(2.5 cm)
1"
(2.5 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
27"
(68.6 cm)
31½"
(80 cm)
18" min.*
(45.72 cm)
14" max.*
(35.6 cm)
7"* (17.8 cm)
9"*
(22.9 cm)
7"* (17.8 cm)
5"**
(12.7 cm)
31
¹₂"
(80.0 cm)
27"
(68.6 cm)
1"*
(2.5 cm)
1" 1"
(2.5 cm)
(2.5 cm)
