Maytronics Dolphin DYNAMIC 2002 - Page 17

III. Testing the Dolphin
Step 3. Repairing/replacing cable
Push the wires into the
triangle end as
pictured. The white
wire will always be to
the right of the
channel in the
connector, the black
wire to the left, and
the red wire (if
present) in the back.
To replace Amphenol
plug, first cut off
molded end.
17
