Table 2 – MAZ–650136 dump-truck technical data
Parameter name Parameter value
Total weight of the loaded truck, kg
12420
(12650)
Technologically allowed total mass of the truck taking into account the
driver’s weight, kg
33500
Distribution of technologically allowed total mass, kg:
– first axle
– second axle
– third axle
7500
13000
13000
Technologically allowed load capacity, kg 21000
Engine
Deutz TCD 2013 L06
4V code C4SF235
Rated engine power, kWt 235
Gearbox (make) ZF 9S1315
Maximal vehicle speed, km/h 100,0
Control fuel consumption l/100 km of the way at the movement of the
vehicle at a constant speed of 60 km/h, not more than
25,5
Wheels Disk, 9,00×22,5
Minimal radius of truck turning endwise of the front external (relative to
the turn center) wheel trace, m, not more than
8,9
Outer minimal turning radius of the truck between walls, m, not more 9,66
Turning angles of the inner (relative to the turn center) wheel to the left
and to the right
45 ±1
Note:
1 Permissible lad
en mass of the chassis with the cab deviation is plus 3%. Bottom weight limit is not
limited.
2
Total weight of the loaded truck is truck weight with the cooling liquid, Ad Blue, lubrication, window
washer liquid, fuel (tank, filled up not less than to 90% of the rated capacity), noise insulating screens, spare
wheel.
3 Figures in the brackets is truck weight with extra equipment (independent liquid heater, rear towing
coupler, radio set or recorder, independent air heater of the cab, fire extinguisher, roll backstops, top sleeping
berth, platform, standard set of spare parts and tools).
4 If speed limiter is installed, maximum speed is (85+4) km/h.
5 Control fuel consumption serves for the determination of the truck technical condition and is not an
operating rate.
