Table 3 –MAZ–555035 dump-truck technical data
Note:
1 Permissible lad
en mass of the chassis with the cab deviation is plus 3%. Bottom weight limit is not
limited.
2
Total weight of the loaded truck of standard composition is truck weight with the cooling liquid,
clutch drive liquid, lubrication, window washer liquid, fuel (tank, filled up not less than to 90% of the rated
capacity), CMR installation elements and Ad Blue, spare wheel, standard set of spare parts and tools, safety
belts, door lock and starting switch keys, first aid kit case, warning triangle, operation documentation, fire
extinguisher, two roll backstops, side protection, rear protection.
3 Figures in the brackets is the
weight of the loaded truck of standard composition with extra equipment
(independent heater of the engine and the cab, independent air cab heater, sleeping berth, air conditioner,
front protecting device, patched on sides (for dump-trucks), awning (for dump-trucks), spade (for dump-
trucks), ASR, radio or CD recorder, mudguards, set of spare parts and tools as requested.
Parameter value for a
truck
Parameter name
With low
sides
With high
sides
Total weight of the loaded truck, kg 8120 (8350) 8320 (8550)
Technologically allowed total mass of the truck taking into account the
driver’s weight, kg
19000 20500
Distribution of technologically allowed total mass, kg:
– first axle
– second axle
7500
11500
7500
13000
Technologically allowed load capacity, kg 10800 12100
Engine
Deutz TCD 2013 L04 4V
code C4SF158
Rated engine power, kWt 158
Gearbox (make) ZF 6S 850
Maximal vehicle speed, km/h 100,0
Control fuel consumption l/100 km of the way at the movement of the
vehicle at a constant speed of 60 km/h, not more than
19,5
Wheels Disk; 9,0×22,5
Tyres, size 315/80R22,5
Minimal radius of truck turning endwise of the front external (relative
to the turn center) wheel trace, m, not more than
7,4
Platform volume, m
3
6,2 8,4
