Maintenance and Care
Owner Maintenance
4. Turn the screw anticlockwise and
remove it, and then partially peel back
the mudguard.
5. Disconnect the connector from the
bulb.
6. Detach the sealing cover from the bulb.
Retaining spring
Sealing cover
7. Unhook the bulb retaining spring.
8. Swing the retaining spring out and
away to free the headlight bulb.
9. Carefully remove the headlight bulb
from the socket by pulling it straight
back.
10. Replace the bulb.
11. Install the new bulb in the reverse order
of the removal procedure.
NOTE
To replace the bulb, contact an
expert repairer, we recommend an
Authorised Mazda Repairer.
If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
Use the protective cover and carton
of the replacement bulb to dispose
of the old bulb promptly out of the
reach of children.
When reinstalling the sealing cover,
make sure it is fi tted correctly.
Running lights/Position lights (With
LED headlights)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with
the unit. We recommend an Authorised
Mazda Repairer when the replacement is
necessary.
