Maintenance and Care
Owner Maintenance
Front direction indicator lights,
Running lights
*
/Position lights (With
halogen headlights)
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right, and turn
off engine.
2. Make sure the headlight switch is off.
3. Pull the centre of each plastic retainer
and remove the retainers.
Removal
Installation
4. Turn the screw anticlockwise and
remove it, and then partially peel back
the mudguard.
5. Turn the socket and bulb assembly
anticlockwise and remove it.
6. Disconnect the bulb from the socket.
Front direction indicator lights
Running lights/Position lights (With
halogen headlights)
*
To Next Page
