Maintenance and Care
Owner Maintenance
Side direction indicator lights, High-
mount brake light
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with
the unit. We recommend an Authorised
Mazda Repairer when the replacement is
necessary.
Rear direction indicator lights, Brake
lights/Tail lights
Saloon
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Remove the cover.
3. Turn the socket and bulb assembly
anticlockwise and remove it.
4. Disconnect the bulb from the socket.
Rear direction indicator lights
Brake lights/Tail lights
5. Install the new bulb in the reverse order
of the removal procedure.
6. Insert the cover tabs and install the
cover.
NOTE
Verify that the cover is securely
installed.
