Mazda 2002 Millenia - Instrument Cluster and Indicators; Meters and Gauges

5-18
Driving Your Mazda
Form No. 8Q47-EA-01F
Instrument Cluster and Indicators
When the engine switch is in the ON position, the dashboard gauges illuminate.
1 Speedometer .............................................................................................................5-19
2 Odometer and Trip Meter .........................................................................................5-19
3 Tachometer ...............................................................................................................5-20
4 Engine Coolant Temperature Gauge ........................................................................5-20
5 Fuel Gauge ...............................................................................................................5-20
Meters and Gauges
J76Y.book Page 18 Wednesday, March 27, 2002 5:04 PM
