Mazda 2002 Tribute - Page 195

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
DIODE — —
H/L RELAY
MICRO
— Headlamp (High/Low, Right/Left Relay)
———
INJ 30A** EEC (VPWR), EVR, MAF, IAC, Bulkhead
MAIN 120A Main
ALT 15A* Alternator/ Regulator
(DRL) 15A* DRL Unit (feed), DRL Relay
(DRLZ)
(HELV)
15A*(DRLZ)
10A(HLEV)
Daytime Running Lamps (DRL) Module,
HLEV
PWR 1 15A* Auxiliary Power Point
FOG 20A* Foglamps RH/LH, Foglamp Indicator
A/C 15A* A/C Clutch
(ABS) 25A* Anti-Lock Brake System SOL
PWR 2 15A* Auxiliary Power Point
IG MAIN 40A** Starter
HTR 40A** Blower Motor, Blower Motor Relay
BTN 1 40A** JB — Acc. Relay, Radio, Cigar Lighter,
Cluster, Power Mirror, GEM, Electronic
Flasher Control
(ABS) 60A** Anti-Lock Brake System Motor
BTN 2 40A** JB — Radio, Cluster, Dome Lamps, Map
Lamps, Cargo Lamps, Cruise Control,
Power Seat, Horn
MAIN FAN 40A**
(2.0L)
50A(3.0L)
Main Fan
R DEF 30A** Rear Defroster
ADD FAN 40A**(2.0L)
50A(3.0L)
Add Fan
EEC MAIN
ISO
— EEC Relay
Roadside Emergencies
195
