Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
FUEL PUMP
ISO
— Fuel Pump Relay
MAIN FAN
ISO
— Low Speed Fan Control Relay (2.0L
Engine)
High Speed Fan Control Relay 1 (3.0L
Engine)
ADD FAN
ISO
— High Speed Fan Control Relay 1 (2.0L
Engine)
Low Speed Fan Control Relay (3.0L
Engine)
DEF RELAY
ISO
— Rear Defroster Relay
ST RELAY
ISO
— Starter Relay
ADD FAN 2
ISO
— High Speed Fan Control Relay 2 (3.0L
Engine)
Medium Speed Fan Control Relay (2.0L
Engine)
FOG RELAY
MICRO
— Foglamp Relay
A/C RELAY
MICRO
— A/C Clutch Relay
TEMPORARY SPARE TIRE INFORMATION
The temporary spare tire for your vehicle is labeled as such. It is smaller
than a regular tire and is designed for emergency use only.
WARNING: If you use the temporary spare tire continuously or
do not follow these precautions, the tire could fail, causing you
to lose control of the vehicle, possibly injuring yourself or
others.
Roadside Emergencies
