Black plate (36,1)
Stowing the third-row seat
1. Insert the seat belts in the retainers.
2. Remove the head restraint and set them
aside temporarily (page 2-22).
3. Pull strap A and ease the seatback
toward the front of the vehicle with
your other hand and be sure it locks
with a click.
Strap A
4. Pull strap B and lift the combined
seatback and seat bottom up to vertical
with your other hand. Gently lower the
seat into the seat well.
Strap B
5. Insert the head restraints between the
floor and seat at the positions indi cated
on the labels.
Labels
Raising the third-row seat upright for
road use
1. Clear the entire cargo floor.
2-24
Essential Safety Equipment
Seats
Mazda MPV_8T51-EC-04G_Edition3 Page36
Friday, December 17 2004 11:10 AM
Form No.8T51-EC-04G
