Engine Compartment Overview
Battery
Engine oil dipstick
Engine oil-filler cap
Air filter
Engine coolant reservoir
Cooling system cap
Brake/Clutch fluid
reservoir
Automatic transmission fluid-level dipstick
(only for automatic transmission)
Windshield washer
fluid reservoir
Fuse block (next
to air filter)
Fuse block
(near battery)
