Except U.S.A. and CANADA
(ILSAC)
The quality d esignation SL, or ILSAC
must be on the label.
5W-20
120
100
80
60
40
20
0
–20
5040
30
20
10
0
–10
–20
–30
qInspecting Engine Oil Level
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal
operating temperature.
3. Turn it off and wait at least 5 minutes
for the oil to return to the oil pan.
4. Remove the engine cover.
5. Pull out the dipstick, wipe it clean, and
reinsert it fully.
Full
Low
OK
6. Pull it out again and examine the level.
It's OK between L and F.
But if it's near or below L, add enough
oil to bring the level to F.
CAUTION
Don't add engine oil over F. This may
cause engine damage.
The distance between L and F on the
dipstick represents the following:
Oil capacity
L (US qt, Imp qt) 1.7 (1.8, 1.5)
Maintenance and Care
Owner Maintenance
8-13
