DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
18 AUDIO 30 A Audio system (BOSE Sound System-equipped model)
19 ABS IG 10A ABS
í
20 FOG 15 A Fog lights
í
21 HORN 15 A Horn
22 ―――
23 H/CLEAN 20 A ―
24 F/PUMP 15 A Fuel pump
25 P/ST IG 10A Power steering
26 A/C MAG 10A Air conditioner
27 TCM 15A Transmission control module
28 ―――
29 ―――
30 ENG +B 10A PCM
31 ROOM 15 A Interior lights
32 ENG BAR 4 10A O
2
heater
33 ENG BAR 3 10A O
2
heater
34 EGI INJ 10A Injector
35 ENG BAR 1 10A Air flow sensor
36 ENG BAR 2 10A EGR control valve
8-56
Maintenance and Care
í
Some models.
