qFuel Gauge
The fuel gauge shows approximately how
much fuel is in the tank. We recommend
keeping the tank over 1/4 full. When the
low fuel warning light illuminates or
when the needle is near E, refuel as soon
as possible.
Low fuel warning light
NOTE
The direction of the arrow ( ) shown
that the fuel-filler lid is on the left side
of the vehicle.
qEngine Oil Pressure Gauge
Engine oil pressure is normal when the
engine oil pressure gauge needle points
halfway between L and H wi th the engine
running.
If the needle on the gauge doesn't move
after starting the engine , follow steps 1
through 3.
If the engine oil pressure gauge moves to
L (low) while you are driving, drive to the
side of the road and park off the right-of-
way. Set the parking brake. Then follow
steps 1 through 3.
1. Turn off the engine and inspect the
engine oil level (page 8-13). If it's low,
add oil.
2. Start the engine.
3. If the needle still doesn't move, have
your vehicle checked at an Authorized
Mazda Dealer.
CAUTION
Don't run the engine if the oil pressure
is low. It could resul t in extensive
engine damage.
Driving Your Mazda
Instrument Cluster and Indicators
5-37
