qSeat Position Memory (Driver's
Seat)
í
One-touch seat position programming and
call up is available on the driver's seat.
CAUTION
When calling up the seat position, do
not place your hands or fingers
around the seat bottom. The seat
moves to the desired position
automatically, and if your hands or
fingers are placed around the seat
bottom, it could cause injury.
Set button
Programming of the driver's seat positions
is possible using the following functions:
l
Programming buttons ― and the
set button.
l
Operation using the advanced key/
retractable type key
Programmed seat positions can also be
called up using the following functions:
l
Programming buttons ― .
l
Operation using the advanced key/
retractable type key
NOTE
Individual seat positions can be programmed
to the number of programming buttons 3
available on the side of the driver's seat, plus
one seat position for each advanced key/
retractable type key used with the vehicle.
Operation using the seat-side buttons
Programming
Seat position programming is possible
when the vehicle is parked.
1. Adjust the seat to the desired position.
For each seat position adjustment
method refer to the following pages:
Seat Slide (page 2-5)
Seat Recline (page 2-6)
Height Adjustment (page 2-6)
2. Press the desired programming button
― while pressing the set button
until a beep sound is h eard.
NOTE
Vehicle maintenance or other reasons
requiring the vehicle battery to be
disconnected will result in the seat position
memory being erased.
In this case, re-program the seat positions.
Seat position call up
With the ignition switch in the LOCK
position, and the driver's door open, press
the programming button
― that has
been progra mmed to the desired seat
position.
Essential Safety Equipment
Seats
2-7
í
Some models.
