Limitations to roll-over detection:
The following illustration is an example of a accident that may not be detected as a roll-
over accident. Therefore, the front seat belt pretensioners and curtain air bags may not
deploy.
Pitch end over end
2-62
Essential Safety Equipment
SRS Air Bags
