Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the diagram.
Jack
Jack lever
Lug wrench
Tiedown eyelet
Flat tire belt
Spare tire carrier bolt socket
In Case of an Emergency
Flat Tire
7-3
