3. Disconnect the bulb by pulling it out.
4. Install the new bulb in the reverse order
of removal.
qReplacing Interior Light Bulbs
Overhead light (Front)/Map lights,
Overhead light (Rear), Vanity mirror
lights
í
1. Wrap a small flathead screwdri ver with
a soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with the flathead screwdriver.
2. Disconnect the bulb by pulling it out.
Overhead light (Front)/Map lights
Overhead light (Rear)
Edge
Vanity mirror lights
í
3. Install the new bulb in the reverse order
of removal.
Trunk light (4 Door)
1. Press both sides of the lens cap to
remove it.
Maintenance and Care
Owner Maintenance
8-55
í
Some models.
